2017+ FK8 Civic Type-R Billet Intercooler Upgrade

Description

Important Notes:

NO CALIBRATION REQUIRED

CURRENT DESIGN RETAINS FACTORY INTERCOOLER BOLTS & HARDWARE
Intercooler Torque Spec: 18 ft/lb

Technical Notes:

It’s no secret that Honda’s 2.0L turbo Civic is extremely susceptible to heat-soak, especially when retaining the factory intercooler. Excessive heat-soak increases the risk of detonation and causes major power-loss due to high charge air and cylinder temperatures. These issues become even more prevalent with spirited driving and/or increased power outputs. The PRL Motorsports intercooler upgrade decreases charge air temperatures while increasing potential airflow with its dense 26.5 x 3.5 x 7.25″ 550+ horsepower rated bar-and-plate core. Our intercooler core which increases surface area|Honda / Acura|85% and internal flow|Honda / Acura|83% to allow optimal cooling and airflow. Billet machined aluminum end tanks maximize efficiency while looking as smooth as they flow!  This intercooler utilizes factory mounting spots with our billet machined end tanks as well as all factory air ducts/shrouds. To maintain consistency with most of our PRL product line, no cutting, fitting or trimming is required. Kits will come with all hardware needed for a seamless install.

Performance Gains:

Increased turbocharger spool
3 horsepower & 11 ft/lb torque gains|Honda / Acura|simply bolting on
Major mid-range power gains
50+ F degree drop in post charge air temperature at peak
Average of 32 F degree drop in post charge air temperature
Increased efficiency & consistency in power delivery
Increased engine safety

Kit Includes:

(1) Intercooler Assembly
(1) Cardboard Stencil w/ “PRL” Logo
(1) Cardboard Stencil w/ ‘R “PRL” Logo
(2) Buna O-Ring


Fits all 2017-2021 Civic Type-R
Fits all variant models including RHD, International Models, Etc.
Fits factory charge piping or pair with PRL Motorsports Charge Pipe Upgrade Kit for the best performance.
